A pillar mounted jib crane is a versatile lifting solution commonly used for small to medium load handling in workshops, production lines, warehouses, and maintenance areas. Known for its compact structure and reliable performance, this crane provides high efficiency and flexible operation. By allowing lifting and rotation within a three-dimensional workspace, it offers greater maneuverability compared to conventional overhead lifting systems, especially in areas requiring frequent localized handling or where equipment is densely arranged.
This type of jib crane features light working duty, making it suitable for repetitive lifting tasks. It primarily consists of a vertical column, slewing arm, rotating mechanism, and electric hoist. The column is firmly secured to the floor using anchor bolts, ensuring stability during operation. The slewing mechanism—typically driven by a cycloidal pin gear reducer—allows smooth and controlled rotation of the arm. The electric hoist runs along the arm’s I-beam track, enabling horizontal travel and vertical lifting.
The crane arm is usually a hollow steel structure, providing high strength while maintaining a lighter overall weight. This design increases lifting efficiency and ensures durability. The trolley mechanism often uses specialized engineering wheels with bearings, reducing friction and allowing smooth movement. Thanks to its small structural size and optimized design, the 1 ton jib crane effectively increases the hook lifting height and enhances workspace usability.
Common Application Scenarios
• Machining Workshops: In machining or fabrication workshops, a pillar jib crane is frequently used to transport workpieces between different machine tools. For example, it can lift semi-finished components onto lathes, milling machines, or CNC machines, eliminating the need for workers to manually push carts or carry heavy parts. This not only improves efficiency but also reduces labor fatigue and improves workplace safety.
• Mold Manufacturing and Injection Workshops: In mold factories, molds typically range from 1 ton to 5 tons. A pillar jib crane can easily lift and position these molds directly onto injection molding machines, stamping machines, or die-casting equipment. It avoids the inconvenience and operational risks of using large mobile cranes inside the workshop, ensuring smoother and safer workflow.
• Assembly and Production Lines: During assembly of heavy machinery or industrial equipment, the pillar jib crane plays a key role in handling components such as motors, pumps, counterweights, or structural frames. It allows precise positioning during assembly, significantly reducing alignment time and improving assembly accuracy.
• Warehouses and Logistic Areas: When installed beside shelves or packing areas, the 1 ton jib crane can efficiently lift goods from pallets or storage racks. Compared to forklifts, it works more flexibly in narrow spaces and eliminates potential floor damage. This makes it ideal for high-density warehouse environments.
Although the freestanding jib crane has a compact structure, its flexible operation, small footprint, and precise lifting capabilities make it an essential tool in machining workshops, warehouses, assembly lines, and various material handling environments. To ensure safe and efficient performance, operators should not only understand its structural components and working principles, but also follow standardized operating practices. Regular inspection of rotating parts, hoist mechanisms, and electrical connections is necessary to reduce wear and prevent malfunctions. With proper training and routine maintenance, a pillar jib crane can significantly improve workflow efficiency, reduce manual labor strength, and deliver stable and reliable lifting support over its long service life.
