Smart Control Double Girder Overhead Crane for Optimized Productivity

A double girder overhead crane is a type of lifting equipment designed with two parallel girder beams that form the bridge, supported by end trucks on each side. In most configurations, the trolley and hoist travel along a rail installed on top of the girders. This design provides a significant advantage in terms of hook height, as positioning the hoist between or above the girders can add an extra 18 to 36 inches of lift—making it highly efficient for facilities that require maximum overhead clearance.

Double girder cranes can be engineered in either top running or under running configurations. A top running double girder bridge crane generally offers the greatest hook height and overhead room, making it suitable for large-scale industrial environments. Because of their robust design, double girder overhead cranes are the preferred solution for heavy-duty applications that demand higher lifting capacities and longer spans. However, the added complexity of their hoist, trolley, and support systems makes them more expensive compared to single girder cranes.

These cranes also place greater demands on a building’s structure, often requiring stronger foundations, additional tie-backs, or independent support columns to handle the increased deadweight. Despite these considerations, double girder bridge cranes are valued for their durability, stability, and ability to perform frequent and demanding lifting operations.

Commonly used in industries such as mining, steel production, railyards, and shipping ports, double girder overhead cranes are versatile enough for both indoor and outdoor applications, whether in a bridge or gantry setup, and remain a cornerstone solution for handling heavy loads safely and efficiently.

♦Space Maker, Building Cost Saving: The double girder overhead crane offers excellent space utilization. Its compact structure allows maximum lifting height, which helps reduce the overall height of buildings and lowers construction costs.

♦Heavy Duty Processing: Designed for heavy-duty operations, this crane can handle continuous lifting tasks in steel plants, workshops, and logistics centers with stable and reliable performance.

♦Smart Driving, Higher Efficiency: Equipped with intelligent control systems, the crane provides smooth traveling, accurate positioning, and reduced energy consumption, improving overall productivity.

♦Stepless Control: Variable frequency drive technology ensures stepless speed control, allowing operators to lift and move loads with precision, safety, and flexibility.

♦Hardened Gear: The gear system is made with hardened and ground gears, ensuring high strength, low noise, and long service life even under tough conditions.

♦IP55 Protection, F/H Insulation: With IP55 protection and F/H class motor insulation, the crane resists dust, water, and heat, extending its durability in harsh environments.

♦Heavy Duty Motor, 60% ED Rating: The heavy-duty motor is specially designed for frequent use, with a 60% duty cycle rating that guarantees reliable operation under heavy loads.

♦Overheating and Overloading Protection: Safety systems automatically prevent damage by monitoring overheating and overloading, ensuring stable performance and protecting equipment.

♦Maintenance Free: High-quality components reduce the need for frequent servicing, making the crane more economical and convenient throughout its life cycle.
